TH6
For Flycart 100 / AGRAS T100
UAV Bracket
Product Overview
High-Precision Release Control
Combined with a laser ranging algorithm, the system achieves meter-level or even sub-meter-level release accuracy. The dynamic locking mechanism further ensures accurate delivery.
Comprehensive Safety and Stability Protection
Automatically identifies and matches the type of Communication Fire-Extinguishing Payload. Automatically sets the optimal detonation height of 6–8 m above ground level based on altitude measurement data, while managing charging and discharging to ensure firefighting effectiveness and payload safety. Equipped with 4–12 LED indicators to display the connection status of the release module and the Communication Fire-Extinguishing Payload in real time. A built-in buzzer provides device status alerts, making the operation process clear and controllable. Integrated safety unlocking and release design, with a built-in anti-misrelease locking mechanism and risk identification function, ensuring safe operation at altitudes of 5–100 m and in complex environments.
Multi-Channel, Modular Release Control
Supports DJI FC100 PSDK intelligent control. The modular release mechanism supports single-channel or multi-channel combined release, breaking the limitation of traditional single-channel release and significantly improving mission flexibility. Supports the CZI visual digital-display remote controller for quick single-channel or multi-channel combined release at short range. Supports optional long-range single-channel release control via the DJI remote controller’s side marker light control function.
Strong Load Capacity and Easy Operation
The main unit adopts a quick-detach and quick-install, non-destructive installation structure. Each hook supports a maximum load of up to 100 kg, with a robust overall structure designed for heavy-load operations.
Redundancy and Expandability
Equipped with a Type-C expansion interface for connecting external devices. In addition to releasing fire-extinguishing payloads, the Flagship Version can also be used to deliver other materials.
Specs
Overall parameters
Model
TH6
Version
V2.0
Compatible Models
DJI FC100 Standard Version, FC100 Flagship Version, T100 Lifting Version
Dimensions
L: 460 × W: 486 × H: 182 mm (±20 mm)
Weight
Standard Version ≤7.4 kg / Flagship Version ≤8.9 kg
Material
Aluminum Alloy + Sheet Metal + Stainless Steel
Installation Method
Screw-fixed installation (replaces the original lifting system, non-destructive installation in the original position)
Control Interfaces
CZI Release Remote Controller, DJI Remote Controller (PSDK), Side Marker Light Control (Optional)
Number of Hooks
Standard Version: 4 hooks / Flagship Version: 6 hooks
Maximum Payload
Recommended single-hook payload ≤100 kg (total payload shall not exceed the official payload capacity of the aircraft)
Expand
Download
Firmware Download
TH6 V2 - Firmware V01.04.02.00
2026-05-14
.bin
TH6 V2 - Firmware Release Notes
2026-05-14
.pdf
